    Corrugated Cardboard Box Rotary Die Cutting Machine Electric Driven Customized Color

    Ask Lasest Price
    Price : USD11600-29000 / set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Brand Name : XINGLONG
    Certification : CE,SGS
    Supply Ability : 200 sets per year
    Delivery Time : 20-30 days
    Model Number : MQ1224
    • Product Details
    • Company Profile

    Corrugated Cardboard Box Rotary Die Cutting Machine Electric Driven Customized Color

    Corrugated cardboard box rotary die cutter making machine


    Product details

    1. lead edge feeding ,save manpower,high speed.
    2. Youli cushion imported from Taiwan or germany
    3. Double-warm abrasive belt cushion correction facility.
    4. Cushion axial floating automatically to improve the utilization rate of cushion.The range of floating is 0-20mm(from middle to left or right)
    5. Speed difference self-compensating function.
    6. The axial adjustment of platen roller is electric/manual, range:0-20mm(left to right )
    7. Die-cutting phase is adjusted by electric planet gears, keyless junction.
    model
    AM1224
    design speed
    180pcs/min
    working speed
    150pcs/min
    die cutting roller dia.
    405/480/540mm

    Die-Cutting Part

    1. Die-cutting roller for the high quality steel materials,30mm thickness, balance correction, hard-chrome plating.
    2. Wallboard for high-quality cast iron material, 50mm thickness, and large processing center production.
    3. Soft-roll automatic grinding institutions to pouches repeat usage, grinding 3-4times;
    4. Line speed automatic compensation to ensure that each batch of cardboard boxes full of die-size line;
    5. Use Imported Polyurethane soft rubber, ease of installation, can cut 12000000 times.;
    6. Mechanical soft roll about 40 mm lateral movement , the pads wear uniform;
    7. 40cr material the use of grinding gears for 6,low noise long life;
    8. Die-cutting roller cylinder automatic separation devices to reduce wear pouches.

    Paper Feeding Part

    1. Adsorption automatic feeder, one-slotting, Cut corner, creasing, drilling.
    2. Feed 10,000 per hour speed, precision die-cutting from+0.75mm to-0.75mm
    3. Phase planetary gear used electric adjustment, turn on and turn down were quick adjustment.
    4. Before manually adjust block cardboard side block electric adjustment
    5. Paper rollers have a plastic face, to prevent cardboard, to increase feed accuracy.



    FQA

    1. Q: What is your delivery term? A: FOB,CIF,CFR usually.

    2.Q: What is your payment? A: T/T.30% deposit, 70% balance before delivery. L/C. 100% at sight. T/T and L/C, 30% TT deposit, 70% L/C. 3.Q: What is your delivery time? A: Die cutting machine, 30-40 days usually. If urgent, 15 days only. Paper cutting machine, 20-30 days usually. If urgent, 15 days only.

    4.Q: What is your warranty and other terms? A: One year warranty. Spare parts are free for customer in 1 year, but customer have to pay delivery. We can send our engineer to customer factory for 7 days free installing and trainning, customer have to pay tickets, visa, meals and hotel. If need more training, $100.00 per day to our engineer.
