Chain Feeding 3 Colors Corrugated Carton Box Flexo Printing Slotting Machine

    Buy cheap Chain Feeding 3 Colors Corrugated Carton Box Flexo Printing Slotting Machine from wholesalers

    Buy cheap Chain Feeding 3 Colors Corrugated Carton Box Flexo Printing Slotting Machine from wholesalers
    • Buy cheap Chain Feeding 3 Colors Corrugated Carton Box Flexo Printing Slotting Machine from wholesalers
    • Buy cheap Chain Feeding 3 Colors Corrugated Carton Box Flexo Printing Slotting Machine from wholesalers

    Chain Feeding 3 Colors Corrugated Carton Box Flexo Printing Slotting Machine

    Ask Lasest Price
    Brand Name : xinglong
    Model Number : XL-YJ
    Certification : CE
    Price : Negotation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 8set/month
    Delivery Time : 20-30 days
    • Product Details
    • Company Profile

    Chain Feeding 3 Colors Corrugated Carton Box Flexo Printing Slotting Machine

    Chain Feeding 3 Colors Corrugated Carton Box Flexo Printing Slotting Machine


    Description:

    1. Chain type hand move feeding cardboard
    2. Adopt 360 degree electric ensure and adjust position ,while working or stop can be adjust quickly and accurately
    3. When machine stopped working ink roller can automatic separate with printing roller facer in order to protect it ,
    4. Ink roller have the separately turn device to prevent ink dried when machine stopped working
    5. Adopt pneumatic locking ,electric separation
    6. Ink supply by pneumatic diaphragm pump
    7. Main transmission gear made by 45 steel after high frequency quench
    8. Transmission part adopt sprinkle lubricating system ,ensure the machine precise and long use time .

    Please contact us for the full version of video.


    Technological parameter:


    Three colors Printing and Slotting machine
    ModelBA2300-410BA2300-480
    Machine inside width (mm)23002300
    Max feeding paper size(mm)1200*21001450*2100
    Max effective printing size(mm)1200*19001450*1900
    Min coverage size(mm)350*500mm350*500mm
    Min slotting space(mm)Thin Blade190*50*190*50190*50*190*50
    Normal Blade250*80*250*80250*80*250*80
    Working speed30-50pcs/min30-50pcs/min
    Standard Thickness of printing plate6mm6mm
    Printing precision±0.75mm±0.75mm
    Thickness of cardboard1.2-9mm1.2-9mm
    Wall thickness40mm40mm
    45mm45mm
    50mm50mm
    Main motor powerAbout 4kwAbout 4kw
